SIMEX ST 200 Asphalt Floats are ideal for creating footpaths, sealing the road shoulders, widening roads and filling set-section trenches with asphalt or waste material. By using the Asphalt Float a contractor can lay asphalt on the footpath without having to pass over a newly laid road as the float extends laterally outside of the skid steer wheel up to 1.62 metres. The lateral slides take the existing surface as reference, whereas the thickness of the spread asphalt can be regulated. The floating transverse tilt can be blocked in case a slide doesn’t touch the ground.
Asphalt Float can be mounted to many different sizes of skid steers, especially smaller units. They can also be used on backhoe loaders and front-end loaders.
Features
- simple to use
- easy to clean
- lightweight for transport
- reduces working time
- clean result
- safe
| SPECIFICATIONS | ST200 |
|---|---|
| Paving width adjustment | hydraulic |
| Asphalt width adjustment (*) | mechanical |
| Asphalt thickness (mm) | 0-100 |
| Transverse tilt | 5 degrees |
| Locking device | yes |
| Side shift | hydraulic |
| Average working speed (m/min) (trenching) | 50-120 |
| Operating weight (kg) (1) | 675 |
| Required Oil Flow (l/min) | 45 |
| Oil Pressure (bar) | 200 |
(*) Independent on RH and LH side.
(1) User is responsible for ensuring that the characteristics of the prime mover suit the weight and specifications of the attachment.
Specifications are subject to change without notice.
